Which Semiconductor Manufacturing Processes Require Ozone?

In semiconductor manufacturing, ozone (O₃), valued for its strong oxidizing properties and reactivity, is widely used across multiple critical processes. Below are the key semiconductor manufacturing steps that require ozone, along with details on its applications:

1. Wafer Cleaning

Purpose: Removes organic contaminants, photoresist residues, and metal impurities from wafer surfaces.
Mechanism: Ozone decomposes to generate reactive oxygen species (O), which oxidize organic contaminants into CO₂ and H₂O. It also oxidizes metal impurities into soluble oxides, facilitating their removal in subsequent cleaning steps.
Advantages: Environmentally friendly with no residue, making it ideal for cleaning processes requiring high cleanliness.

2. Oxide Layer Growth

Purpose: Grows high-quality oxide layers (e.g., SiO₂).
Mechanism: At low temperatures, ozone reacts with silicon surfaces to form silicon dioxide (SiO₂) films.
Advantages: Low-temperature processing suits thermally sensitive materials, producing dense and uniform oxide layers.

3. Atomic Layer Deposition (ALD)

Purpose: Used as an oxidizing agent to deposit high-dielectric-constant (high-k) materials (e.g., HfO₂, Al₂O₃) and metal oxide thin films.
Mechanism: Ozone reacts with precursor materials to form oxide films.
Advantages: Delivers high-quality films, critical for precise deposition in nanoscale device manufacturing.

4. Photoresist Stripping (Ashing)

Purpose: Removes photoresist or performs ashing processes.
Mechanism: Ozone decomposes to generate reactive oxygen, oxidizing photoresist into volatile gases (e.g., CO₂, H₂O).
Advantages: Leaves no chemical residues, making it suitable for high-precision patterning processes.

5. Surface Modification

Purpose: Alters wafer surface properties (e.g., enhancing surface energy or adhesion).
Mechanism: Ozone oxidizes the surface, generating hydrophilic groups (e.g., -OH).
Application: Improves surface characteristics before thin-film deposition or bonding processes.

6. Metal Oxide Etching

Purpose: Etches certain metal oxides (e.g., TiO₂, ZnO).
Mechanism: Ozone reacts with metal oxides to form volatile byproducts.
Application: Enables precise etching in nanodevice manufacturing.

7. Passivation Layer Fabrication

Purpose: Prepares passivation layers (e.g., SiOₓ or SiNₓ) to protect devices from environmental damage.
Mechanism: Ozone reacts with silicon or nitride precursors to form passivation layers.
Advantages: Produces dense passivation layers that effectively block impurities and moisture.

8. CVD (Chemical Vapor Deposition) Processes

Purpose: Uses ozone as an oxidizing agent to deposit oxide thin films via CVD.
Mechanism: Ozone reacts with metal-organic precursors to generate oxide films.
Application: Deposits SiO₂, Al₂O₃, and other oxide films.

9. Contaminant Control

Purpose: Treats process exhaust to decompose hazardous gases (e.g., VOCs).
Mechanism: Ozone oxidizes organic contaminants into harmless CO₂ and H₂O.
Advantages: Environmentally efficient and effective for waste gas treatment.

By integrating ozone into these processes, semiconductor manufacturers achieve higher precision, cleaner results, and compliance with stringent industry standards—making ozone generators indispensable for advanced semiconductor production.
